Specifications

No. of Poles	1P+N
Rated Current (A)	40
Rated Frequency (Hz)	50/60
Rated Short-Circuit Capacity - Icn (kA)	6
Rated Operational Voltage AC (V)	230
Rated Residual Current (mA)	30
Ambient Temperature Range (°C)	-25 to 55
Dimensions (mm)	85H x 69D x 35W
Type of Residual Current	A
Poles	1P+N
Current Rating (A)	40
Family	GSH201
AC Voltage (V)	230/240
Icn-Rated Short Circuit Capacity (kA)	6
Product Type	Residual Current Breaker with Overcurrent
Brand	ABB
Series	GSH201
Ambient Temperature	-25 to 55 deg C
Collection	GSH201
Curve Type	C
Degree of Protection	IP20
Depth	69 mm
Height	85 mm
Mounting Type	DIN Rail
Number of Poles	1P+N
Rated Current	40 A
Rated Frequency	50/60 Hz
Rated Short Circuit Current	30 mA
Rated Voltage	230/240 VAC
Residual Current Type	Type A
Short Circuit Capacity	6 kA
Standards and Approvals	IEC 61009-1, GB/T 16917.1, AS/NZS 61009.1
Terminal Type	Cage
Trip Curve	C Curve
Width	35 mm

Description

The RCBO is a combined MCB/RCD that provides protection against short circuit, thermal overload, and earth leakage. It has a breaking capacity of 6kA at 230VAC and is designed for use in a 1P+N configuration. The RCBO has a current rating of 40A and follows the C curve Type A standard. With a sensitivity of 30mA, it offers reliable detection of earth faults. The RCBO is two modules wide, making it suitable for various electrical installations.

Documents

IPD Product Catalogue

IPD Product Catalogue V17

ABB GSH201C40A30 Residual Current Breaker with Overcurrent 6kA 1P+N-P 30mA 40A C-Curve TypeA DIN Rail Mount IP20

Product Code: GSH201C40A30
