ABB GSH201C8A30 Residual Current Breaker with Overcurrent 6kA 1P+N-P 30mA 8A C-Curve TypeA DIN Rail Mount IP20

Product Code: GSH201C8A30

  • 8 A rated current with 230/240 VAC voltage
  • Compact size: 35 mm width, 85 mm height
  • IP20 protection for safe indoor use
  • Complies with IEC, GB/T, AS/NZS standards
  • Type A residual current with C curve
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Poles 1P+N
Rated Current (A) 8
Rated Frequency (Hz) 50/60
Rated Short-Circuit Capacity - Icn (kA) 6
Rated Operational Voltage AC (V) 230
Rated Residual Current (mA) 30
Ambient Temperature Range (°C) -25 to 55
Dimensions (mm) 85H x 69D x 35W
Type of Residual Current A
Poles 1P+N
Current Rating (A) 8
AC Voltage (V) 230/240
Icn-Rated Short Circuit Capacity (kA) 6
Family GSH201
Product Type Residual Current Breaker with Overcurrent
Brand ABB
Series GSH201
Ambient Temperature -25 to 55 deg C
Collection GSH201
Curve Type C
Degree of Protection IP20
Depth 69 mm
Height 85 mm
Mounting Type DIN Rail
Number of Poles 1P+N
Rated Current 8 A
Rated Frequency 50/60 Hz
Rated Short Circuit Current 30 mA
Rated Voltage 230/240 VAC
Residual Current Type Type A
Short Circuit Capacity 6 kA
Standards and Approvals IEC 61009-1, GB/T 16917.1, AS/NZS 61009.1
Terminal Type Cage
Trip Curve C Curve
Width 35 mm

Description

The RCBO is a combined MCB/RCD that provides protection against short circuit, thermal overload, and earth leakage. It has a breaking capacity of 6kA at 230VAC and is designed for use in a 1P+N configuration. The RCBO has an 8A rating with a C curve and Type A sensitivity of 30mA. It occupies two modules of space.
