IDEC RY2S-ULAC110 Miniature Relay DPDT 3A

Product Code: RY2S-ULAC110

  • Compact miniature design for space-saving
  • Handles 3A current with 110VAC coil voltage
  • DPDT contacts with gold-plated silver material
  • Long electrical life: 200,000 operations
  • Certified by CE, cRuus, and CSA standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts DPDT
Coil Voltage AC (V) 110
Insulation Resistance (MO) 100
Operational Temperature Range (°C) -25 to 50
Contact Resistance (mO) 50
Weight (g) 23
Minimum Mechanical Life 5,000,000
Minimum Electrical Life 200,000
Resistance to Vibrations 10 to 55Hz
Resistance to Shock (m/s²) 100
Product Type Miniature Relay
Brand IDEC
Coil Voltage 110 VAC
Contact Configuration DPDT
Contact Material Gold Plated Silver
Contact Resistance 50 MOhm
Electrical Life 200000 Operations
Humidity 45-85%
Insulation Resistance 100 MOhm
Mechanical Life 5000000 Operations
Model With Indicator
Operational Temperature -25 to 55 deg C
Rated Current 3 A
Shock Resistance 100 ms
Standards and Approvals CE, cRuus, CSA
Vibration Resistance 10-55 Hz
Weight 23 g

Description

The IDEC RY2S-ULAC110 is a DPDT relay designed for reliable performance in various applications. It features gold-plated contacts for enhanced conductivity and durability. This relay offers flexible installation options with blade plug-in or PCB terminals and can be mounted using top mounting, DIN socket, PCB socket, or panel mount socket. Additional functionalities include an indicator light and check button for easy operation monitoring, along with an optional top mounting bracket for secure placement.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
