IDEC RN2S-NL-A115 Miniature Power Relay W/Indicator DPDT 115VAC Coil 5A

Product Code: RN2S-NL-A115

  • 115 VAC, 5 A rated for general use.
  • Durable with 100k electrical operations.
  • Fast operation time of 20 ms.
  • Withstands temps from -40 to 70°C.
  • CE and cRUus certified for safety.
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts DPDT
Coil Voltage AC (V) 115
Operational Temperature Range (°C) -40 to 70
Weight (g) 35
Minimum Mechanical Life 10,000,000
Operating Humidity 35 to 85%
Minimum Electrical Life 100,000
Resistance to Vibrations 10 to 55Hz
Power Consumption (VA) 1.2
Product Type Miniature Power Relay With Indicator
Brand IDEC
Contact Configuration DPDT
Contact Material Ag Alloy
Electrical Life 100000 Operations
Humidity 35-85%
Mechanical Life 10000000 Operations
Operating Time 20 ms
Operational Temperature -40 to 70 deg C
Rated Current 5 A
Rated Power 1.2 VA
Rated Voltage 115 VAC
Standards and Approvals CE, cRUus
Vibration Resistance 10-55 Hz
Weight 35 g

Description

The IDEC RN2S-NL-A115 is a DPDT relay designed for reliable switching in electrical circuits. It operates at 115V AC and can handle up to 5A loads. This relay is equipped with an LED indicator for easy status monitoring. Compatible with various relay sockets, it accommodates different mounting styles to suit diverse installation requirements.
