IDEC PLUG-IN RELAY WITH INDICATOR DPDT 48VDC 10A RH2B-ULDC48

Product Code: RH2B-ULDC48

The IDEC RH2B-ULDC48 is a compact, high-capacity plug-in relay designed for efficient operation. It features a DPDT configuration with a 48VDC coil voltage and can handle a switching current of up to 10A. The relay includes blade-style terminals for easy installation and an LED indicator for status visualization. Its space-saving design does not compromise on power, offering robust switching capabilities suitable for various applications.

Technical Specifications

Operating Humidity 45 to 85% RH (no condensation)
Brand IDEC
Series RH
Operational Temperature Range (°C) -25 to +40
Coil Voltage DC (V) 48
Contact Configuration DPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000 operations
Minimum Mechanical Life 50,000,000 operations
No. of Poles 2P
Rated Current (A) 10
Relay Type RH2 2PDT Relay with LED indicator
Suitable Base SH2B-05C
Terminal Type Blade
Weight (g) 37
