IDEC RH2B-UDC6V Power Relay DPDT 6VDC Coil 10A Blade Terminal

Product Code: RH2B-UDC6V

  • 6 VDC, 10 A rated for reliable performance
  • Durable DPDT blade terminals
  • Silver Cadmium Oxide contacts ensure longevity
  • CE, CSA, RoHS certified for compliance
  • Robust with 50 million mechanical operations
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Insulation Resistance (MO) 100
No. of Poles 2
Power Consumption (W) 0.9
Coil Voltage DC (V) 6
Contacts DPDT
Weight (g) 37
Minimum Mechanical Life 50,000,000
Operating Humidity 45 to 85%
Minimum Electrical Life 200,000
Resistance to Vibrations 10 to 55Hz
Resistance to Shock (m/s²) 1000
Terminal Shape Blade Terminal
Contact Resistance (mO) 50
Product Type Power Relay
Brand IDEC
Contact Configuration DPDT
Contact Material Silver Cadmium Oxide
Contact Resistance 50 MOhm
Electrical Life 200000 Operations
Humidity 45-85%
Insulation Resistance 100 MOhm
Mechanical Life 50000000 Operations
Number of Poles 2
Operating Time 20 ms
Rated Current 10 A
Rated Power 0.9 W
Rated Voltage 6 VDC
Shock Resistance 1000 ms
Standards and Approvals CE, CSA, RoHS
Terminal Type Blade
Vibration Resistance 10-55 Hz
Weight 37 g

Description

The IDEC RH2B-UDC6V is a compact, high-capacity DPDT relay designed for efficient operation in space-constrained applications. It operates on a 6V DC coil voltage and can handle up to 10A of contact capacity. This miniature power relay is engineered to provide reliable switching while optimizing board real estate.
