ABB CRM110DC4L Pluggable Interface Relay 21.2mm W Flat Plug-In Connector Terminal 110VDC 10A

Product Code: CRM110DC4L

  • 110 VDC rated voltage, 10 A current capacity
  • Compact size: 21.2mm W x 35.6mm H x 27.5mm L
  • IP40 protection for reliable operation
  • Operates in -40 to 70°C temperature range
  • Complies with UL, IEC/EN, and CSA standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pluggable Interface Relay
Brand ABB
Contact Configuration 4CO SPDT
Degree of Protection IP40
Function Pluggable Miniature Interface Relay CR-M
Height 35.6 mm
Insulated Voltage 250 V
Length 27.5 mm
Operational Temperature -40 to 70 deg C
Rated Current 10 A
Rated Voltage 110 VDC
Standards and Approvals CAN/CSA C22.2 No.14,IEC/EN 63000,IEC/EN 61810-1,UL 508
Terminal Type Flat Plug-In Connector
Weight 0.033 kg
Width 21.2 mm

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
