ABB CRM120AC2 Pluggable Interface Relay 21.2mm W Flat Plug-In Connector Terminal 120VAC 12A

Product Code: CRM120AC2

  • 120 VAC, 12 A rated for reliable performance
  • Compact design: 21.2 mm width, 35.6 mm height
  • IP40 protection against solid objects
  • Pluggable miniature interface relay CR-M
  • Operates in -40 to 55°C temperature range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Pluggable Interface Relay
Brand ABB
Contact Configuration 2CO SPDT
Contact Rating B300
Degree of Protection IP40
Function Pluggable Miniature Interface Relay CR-M
Height 35.6 mm
Insulated Voltage 250 V
Length 27.5 mm
Operational Temperature -40 to 55 deg C
Rated Current 12 A
Rated Voltage 120 VAC
Standards and Approvals CAN/CSA C22.2 No.14,IEC/EN 63000,IEC/EN 61810-1,UL 508
Terminal Type Flat Plug-In Connector
Weight 0.033 kg
Width 21.2 mm
