IDEC RH1V2-UDC24V Power Relay SPDT 24VDC Coil 10A PCB Terminal

Product Code: RH1V2-UDC24V

  • Rated for 24 VDC, 10 A current
  • SPDT contact configuration
  • PCB terminal type for easy integration
  • Long electrical life: 200,000 operations
  • CE, cRuus, CSA certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Coil Voltage DC (V) 24
Contacts SPDT
Insulation Resistance (MO) 100
No. of Poles 1
Power Consumption (W) 0.8
Weight (g) 24
Minimum Mechanical Life 50,000,000
Operating Humidity 45 to 85%
Minimum Electrical Life 200,000
Resistance to Vibrations 10 to 55Hz
Resistance to Shock (m/s²) 1000
Terminal Shape PCB Terminal
Contact Resistance (mO) 50
Product Type Power Relay
Brand IDEC
Contact Configuration SPDT
Contact Material Silver Cadmium Oxide
Contact Resistance 50 MOhm
Electrical Life 200000 Operations
Humidity 45-85%
Insulation Resistance 100 MOhm
Mechanical Life 50000000 Operations
Number of Poles 1
Operating Time 20 ms
Rated Current 10 A
Rated Power 0.8 W
Rated Voltage 24 VDC
Shock Resistance 1000 ms
Standards and Approvals CE, cRuus, CSA
Terminal Type PCB
Vibration Resistance 10-55 Hz
Weight 24 g

Description

The IDEC RH1V2-UDC24V is a compact, high-capacity PCB relay designed for efficient space utilization. It offers SPDT through 4PDT configurations with 10A contact capacity, suitable for various power applications. Its miniature design does not compromise on power, ensuring large capacity switching in a small footprint.
