IDEC RU2S-D-D12 Plug-In Universal Relay DPDT 12VDC Coil 10A

Product Code: RU2S-D-D12

  • Universal relay with DPDT contact config
  • Handles up to 10 A current
  • Operates on 12 VDC coil voltage
  • Silver alloy contacts for reliability
  • Certified by CE, CSA, Lloyd Register, UKCA
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Coil Voltage DC (V) 12
Contacts DPDT
Weight (g) 35
Minimum Mechanical Life 100,000,000
Operating Humidity 5 to 85%
Resistance to Vibrations 10 to 50Hz
Resistance to Shock (m/s²) 150
Contact Resistance (mO) 50
Product Type Plug-In Universal Relay
Brand IDEC
Series RU
Coil Voltage 12 VDC
Contact Configuration DPDT
Contact Material Silver Alloy
Contact Resistance 50 MOhm
Humidity 5-85%
Mechanical Life 100000000 Operations
Model With Diode(DC Coil Only)
Operating Time 20 ms
Rated Current 10 A
Shock Resistance 150 ms
Standards and Approvals CE, CSA, Lloyd Register, UKCA
Vibration Resistance 10-55 Hz
Weight 35 g

Description

The IDEC RU2S-D-D12 is a compact, environmentally conscious DPDT relay capable of handling 10A at 12V DC. It features a non-polarized LED indicator and mechanical flag for easy status verification. The relay boasts a lead-free, wire-free construction with cadmium-free contacts, ensuring compliance with environmental standards. Additionally, it comes with a snap-on yellow marking plate for clear identification. This product meets stringent safety and performance criteria, being UL Recognized, CSA Certified, and EN Compliant.
