IDEC RU2S-CD-D24 Plug-In Universal Relay DPDT 24VDC Coil 10A

Product Code: RU2S-CD-D24

  • Universal series with DPDT contact config
  • 10A rated current, 24VDC coil voltage
  • Durable silver alloy contacts
  • 100 million mechanical operations lifespan
  • CE, CSA, Lloyd Register & UKCA approved
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Coil Voltage DC (V) 24
Contacts DPDT
Weight (g) 35
Minimum Mechanical Life 100,000,000
Operating Humidity 5 to 85%
Resistance to Vibrations 10 to 50Hz
Resistance to Shock (m/s²) 150
Contact Resistance (mO) 50
Product Type Plug-In Universal Relay
Brand IDEC
Series RU
Coil Voltage 24 VDC
Contact Configuration DPDT
Contact Material Silver Alloy
Contact Resistance 50 MOhm
Humidity 5-85%
Mechanical Life 100000000 Operations
Model With Diode(DC Coil Only)
Operating Time 20 ms
Rated Current 10 A
Shock Resistance 150 ms
Standards and Approvals CE, CSA, Lloyd Register, UKCA
Vibration Resistance 10-55 Hz
Weight 35 g

Description

The IDEC RU2S-CD-D24 is a compact, environmentally conscious DPDT relay capable of handling 10A at 24V DC. It features a non-polarized LED indicator and mechanical flag for easy status verification. The relay boasts lead-free construction and cadmium-free contacts, ensuring minimal environmental impact. Additionally, it comes with a snap-on yellow marking plate for clear identification. This product meets stringent safety standards, being UL Recognized, CSA Certified, and EN Compliant.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
