IDEC RU2S-D-D48 Plug-In Universal Relay DPDT 48VDC Coil 10A

Product Code: RU2S-D-D48

  • Universal relay with DPDT contact config
  • Rated for 10 A and 48 VDC coil voltage
  • Durable silver alloy contacts
  • Mechanical life of 100 million ops
  • Complies with CE, CSA, Lloyd Register, UKCA
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Coil Voltage DC (V) 48
Contacts DPDT
Weight (g) 35
Minimum Mechanical Life 100,000,000
Operating Humidity 5 to 85%
Resistance to Vibrations 10 to 50Hz
Resistance to Shock (m/s²) 150
Contact Resistance (mO) 50
Product Type Plug-In Universal Relay
Brand IDEC
Series RU
Coil Voltage 48 VDC
Contact Configuration DPDT
Contact Material Silver Alloy
Contact Resistance 50 MOhm
Humidity 5-85%
Mechanical Life 100000000 Operations
Model With Diode(DC Coil Only)
Operating Time 20 ms
Rated Current 10 A
Shock Resistance 150 ms
Standards and Approvals CE, CSA, Lloyd Register, UKCA
Vibration Resistance 10-55 Hz
Weight 35 g

Description

The IDEC RU2S-D-D48 is a compact, environmentally conscious plug-in relay offering DPDT contacts with a 10A rating at 48V DC. It features a non-polarized LED indicator and mechanical flag for easy status verification. The relay's lead-free, cadmium-free construction aligns with eco-friendly standards. Additionally, it comes with a snap-on yellow marking plate for clear identification. This relay is UL Recognized, CSA Certified, and EN Compliant, ensuring its reliability and safety in various applications.
