IDEC RU2S-D-D6 Plug-In Universal Relay DPDT 6VDC Coil 10A

Product Code: RU2S-D-D6

  • Universal type with DPDT contact configuration
  • Rated current of 10 A for robust performance
  • Silver alloy contacts ensure reliable conductivity
  • High mechanical life of 100 million operations
  • Complies with CE, CSA, Lloyd Register, UKCA standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Coil Voltage DC (V) 6
Contacts DPDT
Weight (g) 35
Minimum Mechanical Life 100,000,000
Operating Humidity 5 to 85%
Resistance to Vibrations 10 to 50Hz
Resistance to Shock (m/s²) 150
Contact Resistance (mO) 50
Product Type Plug-In Universal Relay
Brand IDEC
Series RU
Coil Voltage 6 VDC
Contact Configuration DPDT
Contact Material Silver Alloy
Contact Resistance 50 MOhm
Humidity 5-85%
Mechanical Life 100000000 Operations
Model With Diode(DC Coil Only)
Operating Time 20 ms
Rated Current 10 A
Shock Resistance 150 ms
Standards and Approvals CE, CSA, Lloyd Register, UKCA
Vibration Resistance 10-55 Hz
Weight 35 g

Description

The IDEC RU2S-D-D6 is a plug-in DPDT relay capable of handling 10A with a 6V DC coil. This compact and versatile relay features an environmentally conscious design, including lead-free construction and cadmium-free contacts. It comes equipped with a non-polarized LED indicator, mechanical flag indicator, and a snap-on yellow marking plate for easy identification. The relay is also UL Recognized, CSA Certified, and EN Compliant, ensuring adherence to quality and safety standards.
