IDEC RU2S-D6 Plug-In Universal Relay DPDT 6VDC Coil 10A

Product Code: RU2S-D6

  • Universal relay with DPDT contacts
  • Rated current of 10A, 6VDC coil voltage
  • Durable silver alloy contact material
  • Mechanical life of 100 million operations
  • Certified: CE, CSA, Lloyd Register, UKCA
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Coil Voltage DC (V) 6
Contacts DPDT
Weight (g) 35
Minimum Mechanical Life 100,000,000
Operating Humidity 5 to 85%
Resistance to Vibrations 10 to 50Hz
Resistance to Shock (m/s²) 150
Contact Resistance (mO) 50
Product Type Plug-In Universal Relay
Brand IDEC
Series RU
Coil Voltage 6 VDC
Contact Configuration DPDT
Contact Material Silver Alloy
Contact Resistance 50 MOhm
Humidity 5-85%
Mechanical Life 100000000 Operations
Model Standard
Operating Time 20 ms
Rated Current 10 A
Shock Resistance 150 ms
Standards and Approvals CE, CSA, Lloyd Register, UKCA
Vibration Resistance 10-55 Hz
Weight 35 g

Description

The IDEC RU2S-D6 is a DPDT plug-in relay designed for versatility and environmental consideration. It features a non-polarized LED indicator, mechanical flag indicator, and snap-on yellow marking plate with additional options available. The relay's lead-free construction and cadmium-free contacts underscore its eco-friendly design. For safety and quality assurance, it is UL Recognized, CSA Certified, and EN Compliant.
