Product Code: RJ2S-CLD-D48

The IDEC RJ Series Slim Line Power Relay is a compact DPDT plug-in relay, designed for efficient space utilization. It operates with a 48VDC coil voltage and supports a switching current of up to 8A across its two poles. The relay features an integrated LED indicator for visibility and a surge suppression diode for enhanced durability. Its large switching capacity makes it suitable for various applications requiring reliable power management in a condensed form factor.

Operating Humidity	5 to 85% RH (no condensation)
Brand	IDEC
Series	RJ
Operational Temperature Range (°C)	-40 to +70
Coil Voltage DC (V)	48
Contact Configuration	DPDT
Contact Material	Silver-nickel alloy
No. of Poles	2P
Rated Current (A)	8
Relay Type	RJ2S 2PDT Relay with LED indicator & diode
Switching Voltage (V)	250 AC / 125 DC
Terminal Type	Blade
Degree of Protection	IP40

Relays

IDEC SLIM LINE PLUG-IN RELAY DPDT 48VDC 8A WITH LED AND SURGE SUPPRESION DIODE

Product Code: RJ2S-CLD-D48
