Novaris SDPV-50-1000-M Photovoltaic Surge Diverter 50 kA (L-L) 50 kA (L-PE) 1000VDC 50 kA 2 Ph

Product Code: SDPV-50-1000-M

  • Rated for 1000 VDC, 50 kA (L-L & L-PE)
  • IP20 protection for safe use
  • Mounts on TS35 DIN Rail
  • Operates from -40 to 85°C
  • Complies with EN50539-11 standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Photovoltaic Surge Diverter
Brand NOVARIS
Base Type 90 Mounting
Connection Type Shunt
Degree of Protection IP20
Humidity 5-95%
Material Thermoplastic
Mounting Type TS35 DIN Rail
Number of Ports 1
Operational Temperature -40 to 85 deg C
Phase 2
Rated Current 50 kA (L-L), 50 kA (L-PE)
Rated Voltage 1000 VDC
Standards and Approvals EN50539-11
Terminal Capacity 35 sq-mm Power, 1.5 sq-mm Alarm

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
