IDEC SJ2S-07L DIN Mount Fingersafe Socket

Product Code: SJ2S-07L

  • Compact dimensions: 75.3 x 55.7 x 12.2 mm
  • Rated current capacity: 8 A
  • High insulation resistance of 100 MOhm
  • Operational temp range: -40 to 70°C
  • IP20 protection rating
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 75.3W x 55.7H x 12.2D
Insulation Resistance (MO) 100
No. of Poles 2
Operational Temperature Range (°C) -40 to 70
Rated Current (A) 8
Rated Insulation Voltage (V) 250 AC/DC
Tightening Torque (Nm) 1
Suitable For RJ1S
Weight (g) 34
Operating Humidity 5 to 85%
Resistance to Vibrations 10 to 55Hz
Resistance to Shock (m/s²) 1000
Product Type DIN Mount Fingersafe Socket
Brand IDEC
Degree of Protection IP20
Depth 12.2 mm
Height 55.7 mm
Humidity 5-85%
Insulation Resistance 100 MOhm
Number of Poles 2
Operational Temperature -40 to 70 deg C
Rated Current 8 A
Shock Resistance 1000 ms
Standards and Approvals CE EN61810-1, CSA C22.2 14 1608322, CSA File LR35144, EN61810-1, UL File E55996, UL508, VDE
Vibration Resistance 10-55 Hz
Weight 34 g
Width 75.3 mm

Description

The IDEC RJ2S Relay Base, model SJ2S-07L, is a finger-safe terminal block designed for secure DIN rail mounting. This relay base ensures a safe and reliable connection point for control systems and electrical circuits.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
