Specifications

Maximum Continuous Operating Voltage MCOV AC (V)	30
Maximum Continuous Operating Voltage MCOV DC (V)	38
Maximum Discharge Current (8/20µs) - Imax (kA)	2 (per line) ,4 ( common mode)
Operational Temperature Range (°C)	-40 to 70
No. of Lines	1 x RJ45
Voltage Protection Level (1kV/µs) - Up (kV)	0.08 (L-L), 0.75 (L-PE)
Maximum Load Current - I? (A)	1
Product Type	Surge Protection
Brand	NOVARIS
Capacitance	10 nF
Connection Type	Series
Degree of Protection	IP20
Humidity	5-95%
Material	Metal
Mounting Type	Inline/TS35 DIN Rail
Number of Lines	(1) RJ45
Operational Temperature	-40 to 70 deg C
Rated Current	2 kA (Per Line), 4 kA (Common Mode)
Rated Voltage	30 VAC
Resistance	0.1 Ohm
Response Time	<5 ns
Standards and Approvals	IEC 61643-21, AS/NZS 1768, UL 1449, ITU-T K.44
Voltage Protection Level	0.08 kA (L-L), 0.75 kA (L-PE)
Weight	200 g
