SCHMERSAL AZ17-02ZI-B5 SAFETY SWITCH WITH SEPARATE ACTUATOR 101122854

Product Code: 101122854

The Schmersal AZ17 safety switch is engineered for machine safety applications, particularly suitable for hinged guards. This robust thermoplastic device features a separate actuator and two safety contacts with an opener (NC) switching element. It offers reliable termination through its IDC connector and can handle a thermal test current of 10 A. With utilisation categories of AC-15: 230 VAC at 4 A and DC-13: 24 VDC at 4 A, it ensures compatibility with various control voltages. The AZ17 series is designed without auxiliary contacts, focusing on straightforward functionality and secure operations in industrial environments.

Technical Specifications

Actuator Type Magnet
Enclosure Material Metal, zinc die-cast
Gross Weight (g) 650
Net Weight (g) 200
Installation Conditions Arbitrarily
Wire Cross-Section 0.75 mm
Enclosure Coating Material Painted
Maximum Temperature (°C) 80
Minimum Ambient Temperature (°C) -25
Minimum Temperature (°C) -30
Brand SCHMERSAL
Series AZ17
Working Principle Magnetic drive
Housing Construction Form Norm construction design
EAN 4030660000000
eCl@ss Number, Version 9.0 27-27-26-01
Coding Level According to EN ISO 14119 Low
ETIM 7.0 EC002593
ETIM 6.0 EC000030
eCl@ss Number, Version 11.0 27-27-24-03
Protection Class of Operating Resource 2
Cable Note All indications including the conductor ferrules.
Recommended Safety Switchgear PROTECT PSC1 | SRB-E-301ST | SRB-E-201LC
Maximum Ambient Temperature (°C) 50
Maximum Cable Cross Section (mm²) 2.5
Minimum Cable Cross Section (mm²) 0.34
Mounting Type Snaps onto standard DIN rail to EN 60715
Storage Temperature (°C) 25 to 85
Contact Material Silver
Maximum Actuating Speed (m/s) 1
Maximum Fuse Rating 6 A gG D-fuse
Maximum Switching Capacity (W) 7.2
Minimum Actuating Speed (mm/min) 1
Minimum Mechanical Life 1000000 Operations
Minimum Positive Break Force (N) 20
No. of Auxiliary Contacts 2
No. of Safety Contacts 1
Overvoltage Category 3
Rated Impulse Withstand Voltage (kV) 6
Rated Insulation Voltage (V) 400
Rated Operating Current (mA) 50
Rated Short-circuit Current (A) 400
Resistance to Shock (g/ms) 110 / 4 - 30 / 18
Switching Element 1 NO contact, 2 NC contacts
Switching Principle Snap action
Terminal Type Screw terminals M20 x 1.5
Height (mm) 69
Utilisation Category DC-13
Width (mm) 45
Sensor Length (mm) 30
Sensor Height (mm) 74.1
Degree of Protection IP67
Pollution Degree 3
Standards EN IEC 60947-5-1 / EN IEC 60947-1
