SCHMERSAL AZ17-11ZRK-ST SAFETY SWITCH WITH SEPARATE ACTUATOR 101140774

Product Code: 101140774

The Schmersal AZ17 Series Safety Switch is a robust machine safety solution designed with a thermoplastic enclosure and a separate actuator to ensure secure operation. This switch boasts a higher latching force for reliable engagement and includes both auxiliary and safety contacts, each with one contact point. It features an M12 4-pole connector plug with A-coding for straightforward connectivity. The switching element comprises both NO and NC contacts, accommodating various circuit designs. With a thermal test current of 10 A, it operates efficiently under utilisation categories AC-15 (230 VAC at 4 A) and DC-13 (24 VDC at 4 A), making it versatile for different electrical requirements. Ideal for enhancing machine safety, the AZ17 series is engineered to meet demanding industrial standards.

Technical Specifications

Brand SCHMERSAL
Degree of Protection IP67
Maximum Temperature (°C) 80
Minimum Temperature (°C) -30
Series AZ17
