SCHMERSAL BN 20-02ZMAGNETIC REED SWITCH 101057005

Product Code: 101057005

Technical Specifications

Brand SCHMERSAL
Actuating Element Magnet
Degree of Protection IP67
Housing Material Aluminium
Maximum Actuating Speed (m/s) 18
Maximum Ambient Temperature (°C) 90
Maximum Bounce Duration (ms) 0.6
Maximum Switching Capacity (VA) 120
Maximum Switching Capacity (W) 120
Maximum Switching Current (A) 3
Maximum Switching Voltage AC (V) 250
Minimum Ambient Temperature (°C) -25
Minimum Bounce Duration (ms) 0.3
Minimum Mechanical Life 1000000000 Operations
No. of Normally-closed Contacts 2
Recommended Actuator 2 x BP 10
Repeat Accuracy (mm) 0.25
Sensor Height (mm) 52
Sensor Length (mm) 47
Sensor Width (mm) 104
Standards and Approvals EN IEC 60947-5-1
Switching Element Opener (NC)
Switching Frequency 1080000/h
Termination Screw Terminals M20 x 1.5
