SCHMERSAL BN 20-20ZMAGNETIC REED SWITCH 101057006

Product Code: 101057006

Technical Specifications

Housing Material Aluminium
Minimum Ambient Temperature (°C) -25
Brand SCHMERSAL
Recommended Actuator 2 x BP 10
Maximum Ambient Temperature (°C) 90
Actuating Element Magnet
Maximum Actuating Speed (m/s) 18
Maximum Bounce Duration (ms) 0.6
Maximum Switching Capacity (VA) 120
Maximum Switching Capacity (W) 120
Maximum Switching Current (A) 3
Maximum Switching Voltage AC (V) 250
Minimum Bounce Duration (ms) 0.3
Minimum Mechanical Life 1000000000 Operations
No. of Normally-open Contacts 2
Repeat Accuracy (mm) 0.25
Switching Element NO Contact
Switching Frequency 1080000/h
Termination Screw Terminals M20 x 1.5
Sensor Length (mm) 47
Sensor Width (mm) 104
Sensor Height (mm) 52
Degree of Protection IP67
Standards and Approvals EN IEC 60947-5-1
