SCHMERSAL MAGNETIC REEDSWITCH 101143265

Product Code: 101143265

Technical Specifications

Brand SCHMERSAL
Actuator Type Roller lever H65 and bearing block B2
Cable Note All indications including the conductor ferrules.
Coding Level According to EN ISO 14119 High
Contact Material Silver
Degree of Protection IP65
EAN 4030660000000
eCl@ss Number, Version 11.0 27-37-12-13
eCl@ss Number, Version 9.0 27-37-12-11
Enclosure Coating Material Painted
Enclosure Material Brass
ETIM 6.0 EC000223
ETIM 7.0 EC000221
Gross Weight (g) 2432
Height (mm) 98
Housing Construction Form Norm construction design
Maximum Actuating Speed (m/s) 1
Maximum Ambient Temperature (°C) 80
Maximum Cable Cross Section (mm²) 1.5
Maximum Fuse Rating 6 A gG D-fuse quick blow
Minimum Actuating Speed (mm/min) 60
Minimum Ambient Temperature (°C) -25
Minimum Cable Cross Section (mm²) 0.75
Minimum Mechanical Life 1000000 Operations
Minimum Positive Break Force (N) 15
Net Weight (g) 30
No. of Auxiliary Contacts 2
No. of Safety Contacts 1
Overvoltage Category 3
Pollution Degree 3
Rated Impulse Withstand Voltage (kV) 2.5
Rated Insulation Voltage (V) 250
Rated Short-circuit Current (A) 1000
Resistance to Shock (g/ms) 30 / 11
Sensor Height (mm) 100.5
Sensor Length (mm) 56.5
Standards EN IEC 60947-5-3 / BG-GS-ET-14
Storage Temperature (°C) -25 to 70
Switching Element NC contact, NO contact
Switching Principle Slow action
Terminal Type Cable
Utilisation Category DC-13 | AC-15
Utilisation Category DC-13 1.5 A
Wire Cross-Section 13 AWG
Working Principle Electromechanical
