Actuating Element	Magnet
Maximum Actuating Speed (m/s)	18
Maximum Bounce Duration (ms)	0.6
Maximum Switching Capacity (VA)	120
Maximum Switching Capacity (W)	120
Minimum Ambient Temperature (°C)	-25
Minimum Bounce Duration (ms)	0.3
Recommended Actuator	BP 10
Repeat Accuracy (mm)	0.25
Sensor Height (mm)	26
Sensor Length (mm)	24
Sensor Width (mm)	85
Switching Element	NO Contact
Switching Frequency	1080000/h
Termination	Flat Plug-in Connector 4.8mm
Brand	SCHMERSAL
Degree of Protection	IP67
Housing Material	Glass-fibre, Reinforced Thermoplastic
Maximum Ambient Temperature (°C)	90
Maximum Switching Current (A)	3
Maximum Switching Voltage AC (V)	250
Minimum Mechanical Life	1000000000 Operations
No. of Normally-open Contacts	1

Position Switches & Sensors

SCHMERSAL BN 32-10MAGNETIC REED SWITCH 101057228
