Normally open (NO), normally closed (NC), and bistable contacts Actuated with magnets, with or without enclosure Different switching distances depending on the strength of the magnet Can feature very long lifetimes when appropriately fitted and maintained Noncontact, lowforce operated switches Hysteresis in switchon and switchoff points Can switch different currents with different voltages High contact reliability due to enclosed glass tube for protection Enclosures made of thermoplastic, available in different shapes for various applications Fitted with mounting holes, threaded bolts, screwed flanges, or on Crails

Specifications

Ambient Temperature Range (°C)	-25 °C to + 90 °C
Enclosure Material	Glass-fibre Reinforced, Thermoplastic
Maximum Switching Current (A)	3
Maximum Switching Voltage AC (V)	250
Switching Frequency	300/s
Product Type	Magnetic Reed Switch
Brand	SCHMERSAL
Degree of Protection	IP67
Mode of Operation	Magnetic
