Housing Material	Glass-fibre, Reinforced Thermoplastic
Installation Conditions	Quasi-flush
Direction of Motion	Head-on to the Active Surface
Maximum Storage Temperature (°C)	70
Minimum Ambient Temperature (°C)	-25
Minimum Storage Temperature (°C)	-25
Brand	SCHMERSAL
Recommended Safety Switchgear	SRB-E-301ST
Recommended Actuator	BPS 260
Maximum Ambient Temperature (°C)	70
Wire Cross Section (mm²)	0.25mm² (Diameter)
Actuating Element	Magnet
Maximum Switching Capacity (W)	0.24
Maximum Switching Current (A)	0.01
Maximum Switching Frequency (Hz)	5
No. of Cables	6
No. of Normally-closed Contacts	3
No. of Safety Contacts	2
Rated Impulse Withstand Voltage (kV)	0.8
Rated Insulation Voltage (V)	75DC
Rated Short-circuit Current (A)	100
Resistance to Shock (g/ms)	30g / 11ms
Resistance to Vibrations	10 ... 55Hz, Amplitude 1mm
Termination	Cable
Sensor Length (mm)	13
Sensor Width (mm)	26
Sensor Height (mm)	36
Degree of Protection	IP67
Standards and Approvals	EN IEC 60947-5-3, EN ISO 13849-1

Presence Sensing Safety Devices

SCHMERSAL BNS 260-02/01ZG-L 2,0MMAGNETIC SAFETY SENSOR 101193223
