SCHMERSAL BNS 260-02/01ZG-L 5,0MMAGNETIC SAFETY SENSOR 101203879

Product Code: 101203879

Technical Specifications

Brand SCHMERSAL
Actuating Element Magnet
Cable Length (m) 5
Degree of Protection IP67
Direction of Motion Head-on to the Active Surface
Door Hinge Position Left
Housing Material Glass-fibre, Reinforced Thermoplastic
Installation Conditions Quasi-flush
Maximum Ambient Temperature (°C) 70
Maximum Storage Temperature (°C) 70
Maximum Switching Capacity (W) 0.24
Maximum Switching Current (A) 0.01
Maximum Switching Frequency (Hz) 5
Minimum Ambient Temperature (°C) -25
Minimum Storage Temperature (°C) -25
No. of Cables 6
No. of Normally-closed Contacts 3
No. of Safety Contacts 2
Rated Impulse Withstand Voltage (kV) 0.8
Rated Insulation Voltage (V) 75DC
Rated Short-circuit Current (A) 100
Recommended Actuator BPS 260
Recommended Safety Switchgear SRB-E-301ST
Resistance to Shock (g/ms) 30g / 11ms
Resistance to Vibrations 10 ... 55Hz, Amplitude 1mm
Sensor Height (mm) 36
Sensor Length (mm) 13
Sensor Width (mm) 26
Standards and Approvals EN IEC 60947-5-3, EN ISO 13849-1
Termination Cable
Wire Cross Section (mm²) 0.25mm² (Diameter)
