Schmersal 101184380 Magnetic Safety Sensor

Product Code: 101184380

  • Rated for 30 VDC and 0.4 A
  • Durable with 25M mechanical cycles
  • IP67 protection, robust in harsh conditions
  • Operates from -25 to 70°C
  • Compact size: 13 x 26 x 36 mm
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Maximum Temperature (°C) 70
Minimum Temperature (°C) -25
Nominal Output Current (A) 0.4
Rated Maximum Operational Voltage DC (V) 30
Nominal Power (W) 10
Product Type Safety Sensor
Brand SCHMERSAL
Series BNS260
Actuating Element Magnet
Degree of Protection IP67
Housing Material Glass Fibre Reinforced Thermoplastic
Mechanical Life 25000000 Cycles
Mounting Type Quasi-Flush
Number of Poles 6
Operational Temperature -25 to 70 deg C
Rated Current 0.4 A
Rated Frequency 5 Hz
Rated Insulation Voltage 50 VAC
Rated Power 10 VA
Rated Voltage 30 VDC
Sensor Size 13 mm L x 26 mm W x 36 mm H
Short Circuit Protection 100 A
Standards and Approvals BG-GS-ET-14; EN IEC 60947-5-3; EN ISO 13849-1
Vibration Resistance 10-55 Hz

Description

The Schmersal BNS260 series safety sensor is a robust machine safety solution designed with a thermoplastic enclosure to ensure durability. This sensor features a magnetic actuating element and is suitable for applications requiring two openers and one shutter. It includes two safety contacts for reliable operation. The left-hinged door design integrates with an 8 mm 6-pole connector with latching interlocking, ensuring secure connections. With a switching voltage of 30 VDC, current of 0.4 A, and capacity of 10 VA, this sensor maintains efficient performance in various industrial settings. Ideal for engineers looking for dependable safety sensors within the machine safety category.
