SCHMERSAL MAGNETIC SAFETY SENSOR 101118833

Product Code: 101118833

Technical Specifications

Brand SCHMERSAL
Actuator Type Roller lever H65
Cable Length (m) 10
Contact Material Silver
Degree of Protection IP65
Enclosure Material Metal film
Height (mm) 32
Maximum Actuating Speed (m/s) 1
Maximum Ambient Temperature (°C) 75
Maximum Cable Cross Section (mm²) 1.5
Minimum Cable Cross Section (mm²) 0.34
Mounting Type Snaps onto standard DIN rail to EN 60715
No. of Safety Contacts 1
Overvoltage Category 3
Pollution Degree 3
Rated Impulse Withstand Voltage (kV) 4
Terminal Type Screw terminals
Utilisation Category DC-13 | AC-15
Rated Insulation Voltage (V) 500
Width (mm) 22.5
Cable Note All indications including the conductor ferrules.
Coding Level According to EN ISO 14119 Low
EAN 4030660000000
eCl@ss Number, Version 11.0 27-27-26-03
eCl@ss Number, Version 9.0 27-27-26-01
Enclosure Coating Material Painted
ETIM 6.0 EC000030
ETIM 7.0 EC000222
Gross Weight (g) 281.74
Housing Construction Form Norm construction design
Installation Conditions Arbitrarily
Maximum Fuse Rating 6 A gG D-fuse
Maximum Switching Capacity (VA) 10
Minimum Actuating Speed (mm/min) 160
Minimum Mechanical Life 1000000 Operations
Minimum Positive Break Force (N) 40
Net Weight (g) 1070
No. of Auxiliary Contacts 4
Number of Normally Closed (NC) Contacts 2
Rated Operating Current (mA) 50
Rated Short-circuit Current (A) 400
Recommended Safety Switchgear SRB-E-301ST | SRB-E-201LC
Resistance to Shock (g/ms) 110 / 4 - 30 / 18
Sensor Height (mm) 691
Standards EN IEC 60947-5-3 / BG-GS-ET-14
Storage Temperature (°C) -25 to 70
Switching Element NO contact, NC contact
Switching Principle Slow action
Utilisation Category DC-13 0.05 A
Width of Sensor (mm) 108
Wire Cross-Section 0.14 mm
Minimum Ambient Temperature (°C) -30
