Schmersal 101169805 Magnetic Safety Sensor

Product Code: 101169805

  • Rated for 250 VAC, 5 A, and 1250 W
  • Durable with 20 million mechanical cycles
  • IP65 protection against dust and water
  • Operates in -25 to 55°C temperature range
  • Complies with BG-GS-ET-14, EN IEC standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Nominal Power (W) 1250
Maximum Temperature (°C) 70
Minimum Temperature (°C) -25
Nominal Output Current (A) 5
Rated Maximum Operational Voltage AC (V) 250
Product Type Safety Sensor
Brand SCHMERSAL
Series BNS333
Actuating Element Magnet
Degree of Protection IP65
Housing Material Glass Fibre Reinforced Thermoplastic
Mechanical Life 20000000 Cycles
Operational Temperature -25 to 55 deg C
Rated Current 5 A
Rated Frequency 5 Hz
Rated Power 1250 W
Rated Voltage 250 VAC
Sensor Size 39 mm L x 52 mm W x 90 mm H
Standards and Approvals BG-GS-ET-14; EN IEC 60947-5-3; EN ISO 13849-1
Vibration Resistance 10-55 Hz
Wire Size 15 AWG

Description

Enhance your machine safety with the Schmersal BNS333 safety sensor, a robust solution designed for industrial applications. This thermoplastic-encased sensor features an integrated safety monitoring module and integral system diagnostics to ensure reliable operation. With coding capabilities and a magnetic actuating element, it provides precise functionality. The unit is equipped with one opener and one safety contact, ensuring secure operations without the need for additional cable wires. It's configured for an active area on the left-hand side and utilizes a screw connection terminal for straightforward installation. Capable of handling up to 250 VAC switching voltage, 5 A switching current, and a switching capacity of 1250 W, this sensor is an essential component in any safety-critical machine setup. Trust in Schmersal's expertise in machine safety to keep your operations secure and efficient.
