SCHMERSAL T. 441-11Y-966BELT ALIGNMENT SWITCH 101081746

Product Code: 101081746

Technical Specifications

Housing Material Grey Cast Iron, Galvanised
Enclosure Coating Material Painted
Contact Opening (mm) 2 x 6
Minimum Ambient Temperature (°C) -30
Brand SCHMERSAL
Maximum Ambient Temperature (°C) 90
Maximum Cable Cross Section (mm²) 2.5
Minimum Cable Cross Section (mm²) 1.5
Contact Material Silver
Maximum Fuse Rating 16 A gG D-fuse
Minimum Mechanical Life 10000000 Operations
No. of Normally-closed Contacts 1
No. of Normally-open Contacts 1
Rated Impulse Withstand Voltage (kV) 6
Rated Insulation Voltage (V) 400
Rated Operational Current AC-15 (A) 4
Rated Operational Voltage AC-15 (V) 400V AC
Switching Element NO Contact, NC Contact
Switching Frequency 3000/h
Switching Principle Slow Action
Termination Screw Terminals M20 x 1.5
Thermal Test Current (A) 16
Utilisation Category AC-15
Sensor Length (mm) 63
Sensor Width (mm) 106
Sensor Height (mm) 99
Castor Diameter (mm) 32
Lever Length (mm) 32
Lever Height (mm) 159
Lever Width (mm) 32
Degree of Protection IP65
Standards and Approvals EN IEC 60947-5-1
