Schmersal 101182735 Safety Hinge Switch 230VAC 1NO+1NC

Product Code: 101182735

  • Rated for 230 VAC, 4 A
  • Durable metal die-cast zinc housing
  • IP65 protection against dust and water
  • Long mechanical life of 1 million cycles
  • Operates in -25 to 65°C range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Maximum Temperature (°C) 65
Minimum Temperature (°C) -25
Product Type Safety Hinge Switch
Brand SCHMERSAL
Series TESF
Action Slow Action
Contact Configuration 1NO+1NC
Contact Material Silver Nickel Alloy
Degree of Protection IP65
Housing Material Metal, Die Cast Zinc
Mechanical Life 1000000 Cycles
Operational Temperature -25 to 65 deg C
Rated Current 4 A
Rated Frequency 1200/h
Rated Insulation Voltage 250 V
Rated Voltage 230 VAC
Sensor Size 21.5 mm L x 141 mm W x 115 mm H
Standards and Approvals BG-GS-ET-15, CCC, cULus, EC002591, EN IEC 60947-5-1
Weight 616 g

Description

Ensure machine safety with the Schmersal TESF Series Safety Switch, designed for robust outdoor mounting. This metal-enclosed hinge safety switch features two auxiliary and two safety contacts, with plug-in connection terminals at the bottom for easy installation. It includes both NO and NC switching elements to accommodate diverse applications. With a thermal test current of 2.5 A, it operates reliably under utilisation categories AC-15 (230 VAC, 2 A) and DC-13 (24 VDC, 1 A), making it a versatile choice for safeguarding equipment in various industrial settings. Trust in Schmersal's commitment to machine safety with this durable and efficient safety switch.
