Schmersal 101182740 Safety Hinge Switch 230VAC 1NO+1NC

Product Code: 101182740

  • Rated for 230 VAC, 4 A
  • Durable metal, die-cast zinc housing
  • IP65 protection for harsh environments
  • Long mechanical life of 1 million cycles
  • Compliant with multiple international standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Maximum Temperature (°C) 65
Minimum Temperature (°C) -25
Product Type Safety Hinge Switch
Brand SCHMERSAL
Series TESF
Action Slow Action
Contact Configuration 1NO+1NC
Contact Material Silver Nickel Alloy
Degree of Protection IP65
Housing Material Metal, Die Cast Zinc
Mechanical Life 1000000 Cycles
Operational Temperature -25 to 65 deg C
Rated Current 4 A
Rated Frequency 1200/h
Rated Insulation Voltage 250 V
Rated Voltage 230 VAC
Sensor Size 21.5 mm L x 141 mm W x 115 mm H
Standards and Approvals BG-GS-ET-15, CCC, cULus, EC002591, EN IEC 60947-5-1
Weight 616 g

Description

Enhance your machine safety with the Schmersal TESF Series Safety Switch. This robust metal-enclosed hinge safety switch features an adjustable switching angle for precise operation. Equipped with two auxiliary and two safety contacts, it ensures reliable connectivity with its top plug-in connection terminal. The switch includes both NO and NC contact elements, supporting a thermal test current of 2.5 A. Optimized for performance, it operates at 230 VAC under AC-15 utilization category with a 2 A rating, and at 24 VDC under DC-13 utilization category with a 1 A rating. Trust in Schmersal's commitment to safety for your machinery applications.
