IDEC YW1S-2E01 Selector Switch 2Position 1NC Left Maintained Round Plastic M3.5 Screw Terminal 30mm W

Product Code: YW1S-2E01

  • Maintained function selector switch
  • Rated current: 10 A, 50/60 Hz
  • Round plastic bezel, 22 mm hole
  • Operates in -20 to 55°C range
  • Meets CSA, IEC, UL standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-closed Contacts 1
Product Type Selector Switch
Brand IDEC
Series YW
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NC
Depth 69.8 mm
Function Maintained
Height 41.4 mm
Insulation Resistance 100 MOhm
Model Maintained
Mounting Hole Diameter 22 mm
Number of Positions 2
Operation Position Left
Operational Temperature -20 to 55 deg C
Rated Current 10 A
Rated Frequency 50/60 Hz
Rated Insulation Voltage 600 V
Standards and Approvals CSA C22.2 No.14, GB/TI4048.5, IEC60947-1, IEC60947-5-1, UL508
Terminal Type M3.5 Screw
Tightening Torque 1 N-m
Width 30 mm

Description

The IDEC YW1S-2E01 Selector Switch is a compact and efficient solution for control operations. It features a 2-position maintained function with 1 Normally Closed (NC) contact. The switch's space-saving design includes 10mm thick contact blocks and a removable operator for ease of use. Its lightweight form factor and separate contact block facilitate straightforward installation and removal, enhancing user convenience in various industrial settings.
