IDEC YW1S-3E11 Selector Switch 3Position 1NO+1NC Round Plastic M3.5 Screw Terminal 30mm W 41.4mm H 69.8mm D

Product Code: YW1S-3E11

  • Selector switch with spring return operation
  • Rated for 10 A, 50/60 Hz frequency
  • IP20/IP65 protection for versatile use
  • Compatible with 22 mm mounting holes
  • Meets CSA, IEC, and UL standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 1
No. of Normally-closed Contacts 1
Product Type Selector Switch
Brand IDEC
Series YW
Bezel Material Plastic
Bezel Shape Round
Contact Configuration 1NO+1NC
Degree of Protection IP20, IP65
Depth 69.8 mm
Height 41.4 mm
Insulation Resistance 100 MOhm
Mode of Operation Spring Return
Model Spring Return Two-Way
Mounting Hole Diameter 22 mm
Number of Positions 3
Operational Temperature -20 to 55 deg C
Rated Current 10 A
Rated Frequency 50/60 Hz
Rated Insulation Voltage 600 V
Standards and Approvals CSA C22.2 No.14, GB/TI4048.5, IEC60947-1, IEC60947-5-1, UL508
Terminal Type M3.5 Screw
Tightening Torque 1 N-m
Width 30 mm

Description

The IDEC YW1S-3E11 is a 3-position selector switch designed for efficient control within electrical circuits. It features a single Normally Open (NO) and one Normally Closed (NC) contact, maintained for consistent operation. The switch boasts a space-efficient design with 10mm thick contact blocks and a plastic bezel for durability. Its compact and lightweight construction, along with the removable operator and separate contact block, simplifies installation and maintenance processes.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
