The HW Series Selector Switch is a robust and reliable component designed for industrial and commercial applications. Crafted with precision, this selector switch meets the demands of various environments, ensuring seamless operation across diverse settings.
With a rated current of 10 A and a frequency range of 50/60 Hz, this switch is well-suited for numerous electrical systems. Its non-illuminated design simplifies integration into existing setups without additional lighting considerations. The operational temperature range from -25 to 60 degrees Celsius ensures functionality in both cold and warm conditions, making it versatile for different climates.
The selector switch features screw-type terminals, facilitating secure connections that are easy to manage during installation or maintenance. With an IP20/IP65 degree of protection, it offers substantial resistance against dust ingress and water jets, enhancing its durability in challenging environments.
Compliance with CE, CSA, and UL standards underscores the product's adherence to international safety and quality benchmarks. This makes it a trustworthy choice for professionals seeking reliable components that meet rigorous industry standards.
Designed with a mounting hole diameter of 22 mm, the HW Series Selector Switch fits seamlessly into standard panel cutouts. It boasts a rated insulation voltage of 600 V and can withstand impulse voltages up to 4 kV, providing excellent protection against electrical surges.
The contact configuration includes one normally open (1NO) and one normally closed (1NC) contact set-up. This versatility allows users to implement complex control schemes easily within their systems. The knob actuator type offers straightforward user interaction while maintaining functionality over time.
Constructed with plastic bezel material, the switch combines lightweight properties with sufficient strength for regular use. The maintained function ensures that once set in position by the operator, the switch remains engaged until manually changed—a feature particularly useful in maintaining consistent system states without continuous input.
Insulation resistance is rated at 50 MOhm which contributes to preventing leakage currents thus enhancing safety during operation. Overall this selector switch provides an effective solution balancing performance reliability ease-of-use all essential factors when selecting components for technical projects demanding precision dependability Manufacturer Part Number: [Not Provided]
