IDEC HW1S-33TF11-K Selector Switch 3Position 1NO+1NC Non-Illuminated Knob Knob Plastic Screw Terminal

Product Code: HW1S-33TF11-K

  • 10A rated current for reliable performance
  • Two-way spring return operation
  • IP20, IP65 protection for durability
  • CE, CSA, UL approved for quality assurance
  • Fits standard 22mm mounting holes
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Components Selector Switch 3 Position Operator Contact Block Adaptor 1 NO Contact Block 1 NC Contact Block
Product Type Selector Switch
Brand IDEC
Series HW
Actuator Type Knob
Bezel Material Plastic
Contact Configuration 1NO+1NC
Degree of Protection IP20, IP65
Illumination Non-Illuminated
Insulation Resistance 50 MOhm
Mode of Operation Two-Way Spring Return
Mounting Hole Diameter 22 mm
Number of Positions 3
Operational Temperature -25 to 60 deg C
Rated Current 10 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 4 kV
Rated Insulation Voltage 600 V
Standards and Approvals CE, CSA, UL
Switch Type Knob
Terminal Type Screw

Description

The IDEC HW1S-33TF11-K is a versatile selector switch featuring a 3-position knob with spring return functionality in both directions. It includes 1 Normally Open (NO) and 1 Normally Closed (NC) contact, suitable for 22mm panel cutouts. The durable plastic bezel ensures longevity, making it ideal for various industrial applications requiring robust control elements.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
