Specifications

No. of Phases	1
Backup fuse rating (A)	20
Maximum Continuous Voltage AC (V)	275
Product Type	Surge Protector
Brand	NOVARIS
Degree of Protection	IP20
Depth	115 mm
Discharge Current	45 kA
Display Type	LED Power
Fuse Rating	20 A
Height	69 mm
Humidity	5-95%
Interrupt Rating	100 A
Material	Aluminium
Modes of Protection	L-N, L-PE, N-PE
Mounting Type	TS35 DIN Rail
Operational Temperature	-40 to 70 deg C
Phase	1
Rated Current	20 A
Rated Short Circuit Current	25 kA
Rated Voltage	230 VAC
Response Time	<5 ns (L-N), <100 ns (N-PE)
Standards and Approvals	IEC 61643-11, AS/NZS 1768, UL 1449, EEE 62.41.2
Tightening Torque	0.5 N-m
Voltage Protection Level	<800 V
Weight	200 g
Width	18 mm
