Specifications

Dimensions (mm)	7W x 110H x 71D
Maximum Continuous Operating Voltage MCOV AC (V)	275
Maximum Discharge Current (8/20µs) - Imax (kA)	1.8, 3.6 (common mode)
Voltage Protection Level (1kV/µs) - Up (kV)	0.45 (L-L, L-PE)
Maximum Load Current - I? (A)	6
Product Type	Surge Protector
Brand	NOVARIS
Series	SSP6A
Base Type	G Direct Earthing
Degree of Protection	IP20
Depth	71 mm
Discharge Current	3.6 kA
Height	110 mm
Modes of Protection	Transverse and Common Modes
Mounting Type	DIN rail
Number of Lines	1 pair
Rated Current	1.8 kA
Rated Voltage	380 VDC
Resistance	0.02 Ohm
Voltage Protection Level	<800 V
Width	7 mm
