Specifications

Product Type	Signal and Power Surge Protection With Base
Brand	NOVARIS
Capacitance	<13 nF
Connection Type	Screw Cage
Degree of Protection	IP20
Depth	110 mm
Height	71 mm
Humidity	5-95%
Material	Polycarbonate
Modes of Protection	Transverse and Common Modes
Mounting Type	TS35 DIN Rail
Number of Lines	1 pair
Operational Temperature	-40 to 70 deg C
Rated Current	4.8 kA (Power), 20 kA (Signal)
Rated Voltage	25 V, 6 V
Resistance	3.9 Ohm
Response Time	<5 ns
Standards and Approvals	IEC 61643-21, AS1768, AS/NZS4117, AS7708
Tightening Torque	0.5 N-m
Voltage Protection Level	<90V Power, 9V Signal
Weight	65 g
Width	12 mm
