Specifications

Dimensions (mm)	70 * 54 * 95 [H * W * D]
Operational Temperature Range (°C)	-40 - 70°C
Rated Operational Voltage AC (V)	230VAC
Type of Mounting	TS35 DIN Rail
Short Circuit Withstand Level (kA)	25kA
Product Type	Surge Diverter
Brand	NOVARIS
Connection Type	Shunt
Degree of Protection	IP20
Depth	95 mm
Display Type	LED Power and Thermal Failure
Fuse Rating	16 A
Height	54 mm
Humidity	5-70%
Material	Aluminium
Modes of Protection	L-N, L-PE, N-PE
Mounting Type	TS35 DIN Rail
Number of Ports	1
Operational Temperature	-40 to 70 deg C
Phase	3
Rated Current	20 kA (L-N), 25 kA (N-PE)
Rated Short Circuit Current	25 kA
Rated Voltage	230 VAC
Response Time	<100 ns (N-PE)
Standards and Approvals	IEC 61643-11:2011, AS/NZS 1768:2007, IEEE 62.41.2:2002, UL 1449 3rd Edition
Tightening Torque	2 N-m
Voltage Protection Level	<0.8 kA (L-N), <1.2 kA (N-PE)
Weight	305 g
Width	70 mm
