Specifications

Dimensions (mm)	73W x 150H x 36D
Lightning Impulse Current (10/350 µs) - Iimp (kA)	35
Nominal Discharge Current (8/20µs) - In (kA)	35
Nominal Voltage AC (V)	400
Reference No.	961140
Weight (kg)	0.59
No. of Conductors	1
Type	Lightning Protection
Weight (g)	592
Maximum Continuous Voltage AC (V)	440
Product Type	Lightning Current Arrester
Brand	DEHN
Cross Section	50 sq-mm Stranded, 35 sq-mm Flexible, 35 sq-mm Stranded, 25 sq-mm Flexible
Degree of Protection	IP20
Depth	73 mm
Fuse Rating	125 A
Height	150 mm
Lightning Current Carrying Capability	50 kArms
Lightning Impulse Current	35 kA
Material	Thermoplastic
Number of Poles	1
Number of Ports	1
Operational Temperature	-40 to 80 deg C
Rated Current	35 kA
Rated Voltage	400 V
Response Time	<= 100 ns
SPD Class	Type 1, Class I
Standards and Approvals	UL, CSA
Voltage Protection Level	<=2.5 kV
Weight	516 g
Width	36 mm
