Product Code: TLB1604P/SE

The TLB series is a powder coat mild steel enclosed load break switch. It features line and load side terminal covers, as well as an opaque liftoff lid. This 4P switch has a current rating of 160A at AC21A (690V) and AC23A (690V). It also has a power rating of 88kW at AC23A (690V). The cable size for this switch is 95mm². With an IP65 rating, it offers protection against dust and water ingress. The dimensions of the switch are 250mm wide, 300mm high, and 150mm deep.

Brand	TELERGON
Cable Cross Section (mm²)	95
Degree of Protection	IP65
Dimensions (mm)	250W X 300H X 150D
IP Rating	IP65
Material	Mild Steel
No. of Poles	4P
Operational Current AC-21A @ 690V (A)	160
Operational Current AC-23A @ 690V (A)	160
Operational Power AC-23A @ 690V (kW)	88
Poles	4P
Rated Operational Current AC-21A 690V (A)	160
Rated Operational Current AC-23A 690V (A)	160
Rated Operational Power AC-23A 690V (kW)	88
Series	TLB
Sizes (mm)	250W x 300H x 150D

Load Break Switches

TELERGON TLB1604P/SE POWDER COAT MILD STEEL ENCLOSED LOAD BREAK SWITCH 160A 4P

Product Code: TLB1604P/SE

Technical Specifications
