When it comes to safeguarding your industrial and commercial electrical systems, choosing the right surge protector is crucial. This particular Surge Protector offers robust protection for sensitive equipment, ensuring reliability and longevity in demanding environments.
Designed for use with a rated voltage of 7 VDC and rated power of 2.2 W, this surge protector efficiently manages electrical surges with its impressive current handling capabilities—5 kA per line and 10 kA in common mode. The shunt connection type enhances its protective abilities, making it a reliable choice for various applications.
One of the standout features is its IP67 degree of protection, providing complete resistance against dust ingress and water immersion up to one meter deep. This makes it ideal for outdoor or harsh indoor settings where exposure to environmental elements is a concern.
The surge protector's compact dimensions—53 mm in length, 24 mm in width, and 27 mm in height—combined with its M20 x 1.5 thread mounting type allow for easy integration into existing setups without requiring significant space or structural modifications.
Operating efficiently between -20°C to 40°C, this unit adapts well to varying temperature conditions while maintaining optimal performance. It meets several rigorous standards and approvals including IEC 60079-0/1/11, IEC 61643-21:2012, AS/NZS 1768:2007, UL 1449 (3rd Edition), UL 497B, and ITU-T K.44:2012—ensuring compliance with international safety regulations.
Weighing just 180 g and constructed from durable stainless steel material ensures not only lightweight handling but also excellent resistance to corrosion—a critical factor when considering long-term installations.
With an exceptional response time of less than five nanoseconds (<5 ns), this surge protector promptly reacts to transient overvoltages thereby protecting connected devices effectively. Its operational humidity range from 5% to 95% further supports usage across diverse climates without compromising on functionality.
The device features a capacitance value of 20 nF alongside a voltage protection level set at an efficient threshold of 45 V which helps prevent damage due both transverse modes as well as common modes thanks largely due having three lines available within design parameters allowing comprehensive coverage during operation cycles ensuring peace-of-mind knowing all bases covered when dealing potential hazards associated such scenarios arise unexpectedly needing attention urgently addressed quickly possible manner every time needed most importantly!
