ABB CT-MVS.12S Time Relay 1CO SPDT Contact 24-240VAC 24-48VDC 4A Screw Terminal

Product Code: CT-MVS.12S

Versatile voltage range: 24-240 VAC, 24-48 VDC
Compact DIN rail mount: 22.5 mm width
Wide operating time: 0.05 s to 300 hr
Reliable protection: IP20, IP50 rated
Certified standards: CAN/CSA, IEC/EN, UL

Specifications

Product Type	Time Relay
Brand	ABB
Contact Configuration	1CO SPDT
Degree of Pollution	IP3
Degree of Protection	IP20, IP50
Height	85.6 mm
Mounting Type	35 x 15 mm DIN Rail, 35 x 7.5 mm DIN Rail
Operating Time	0.05 s-300 hr
Operational Temperature	-20 to 60 deg C
Rated Current	4 A
Rated Frequency	50/60 Hz
Rated Voltage	24-240 VAC, 24-48 VDC
Standards and Approvals	CAN/CSA,IEC/EN,UL
Terminal Type	Screw
Weight	0.107 kg
Width	22.5 mm

Documents

IPD Product Catalogue

IPD Product Catalogue V17
