When it comes to safeguarding your industrial and commercial electrical systems, selecting the right surge protector is critical. This robust surge protector offers a comprehensive solution for protecting sensitive equipment from voltage spikes, ensuring operational continuity and safety in demanding environments.
Designed for versatility, this surge protector operates efficiently at a rated voltage of 230 VDC and supports a wide range of power ratings from 40 to 125 W. It boasts impressive current handling capabilities with options for either 20 kA or 50 kA, making it suitable for various applications that require different levels of protection.
The device features a U-Type connection, which simplifies integration into existing systems. Its compact dimensions—25 mm in width and height, and a depth of 57 mm—make it easy to install even in space-constrained settings. Despite its small size, the unit is built to withstand harsh conditions with an IP55 degree of protection against dust and water ingress.
This surge protector is engineered with durability in mind, operating effectively within an extensive temperature range from -40°C to 85°C. The material construction includes brass with nickel plating, providing both excellent conductivity and corrosion resistance. Weighing only 150 g, it’s lightweight yet sturdy enough for reliable long-term use.
Compatibility with international standards such as IEC61643-21, UL497B, ITU-T K.44, AS/NZS 1768, and IEE C62.41 ensures that this device meets rigorous safety requirements across different regions including Australia.
For telecommunications applications requiring high-frequency performance up to 3 GHz, this unit maintains low capacitance at less than 1 pF while offering a consistent resistance level of 50 Ohm. With female and male connector orientations available, installation flexibility is further enhanced.
Humidity tolerance ranges from as low as 5% up to an impressive maximum of 95%, allowing operation in varied environmental conditions without compromising performance.
Additionally featuring a voltage protection level under <0.82 kV along with signal-earth modes of protection ensures comprehensive safeguarding against transient overvoltages that could otherwise disrupt sensitive electronic equipment.
Overall this surge protector stands out not only due its technical specifications but also through its assured reliability under diverse operational scenarios making it ideal choice those seeking dependable solution their electrical infrastructure needs without unnecessary complexity or cost overheads associated similar products market today
