Novaris MPP-VDSL-IP67 Telephone Line Protector 1.25kA 5kA (Per Line) 200VDC 90mm W 26mm D 26mm H IP67

Product Code: MPP-VDSL-IP67

  • Surge protector with 200 VDC rating
  • Handles up to 5 kA per line
  • IP67-rated, dust and waterproof
  • Compact size: 90x26x26 mm
  • Voltage protection level under 950 V
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 90W x 26H x 26D
Maximum Continuous Voltage DC (V) 200
Maximum Continuous Voltage AC (V) 140
Maximum Discharge Current (8/20µs) (kA) 6 (per Line)
Product Type Telephone Line Protector
Brand NOVARIS
Degree of Protection IP67
Depth 26 mm
Height 26 mm
Lightning Impulse Current 1.25 kA
Rated Current 5 kA (Per Line)
Rated Voltage 200 VDC
Resistance 0.1 Ohm
Voltage Protection Level <950 V
Width 90 mm

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
