Outdoor Isolators & Socket Outlets

IPD IPW WEATHERPROOF ISOLATOR 4P 20A 415V PADLOCAKBLE, IP66 IPW204

Product Code: IPW204

The IPW weatherproof isolator is a 4P (four pole) device with a current rating of 20A and voltage rating of 415V. It is designed to be padlockable and has an IP66 rating, ensuring protection against dust and water ingress. This isolator can accommodate cables with a maximum area of 25mm² and features four M25 gland entries for easy installation. The padlockable handle allows for secure operation from both the front and rear entries, while the high strength locking screws provide added security. Additionally, this isolator includes earth and neutral terminals for proper grounding. It has been tested to meet the standards of IEC 60947.3 and AS3133, ensuring its reliability and safety. In terms of dimensions, the IPW weatherproof isolator measures 82.5mm in width, 167mm in height, and 89mm in depth. Each pack contains a quantity of 20 units.

Technical Specifications

Brand IPD
Degree of Protection IP66
Dimensions (mm) 82.5W x 167H x 89D
Gland Entries 4 x M25
Maximum Cable Cross Section (mm²) 25
No. of Poles 4
Pack Quantity 20
Rated Current (A) 20
Rated Voltage (V) 415
