IPD IPW WEATHERPROOF ISOLATOR 1P 63A 240V PADLOCAKBLE, IP66 IPW631

Product Code: IPW631

The IPW weatherproof isolator is a 1P (single pole) device with a rating of 63A and operates at 240V. It is designed to be padlockable and has an IP66 rating, ensuring protection against dust and water ingress. This isolator can accommodate cables with a maximum area of 25mm² and features 4 x M25 gland entries for easy installation. The padlockable handle allows for secure operation from both the front and rear entries, while the high strength locking screws provide added security. Included with the isolator are earth and neutral terminals, ensuring proper grounding and connection. It has been tested to meet the standards of IEC 60947.3 & AS3133, guaranteeing its reliability and performance. In terms of dimensions, the isolator measures 82.5mm in width, 167mm in height, and 89mm in depth. Each pack contains a quantity of 20 isolators.

Technical Specifications

Brand IPD
Degree of Protection IP66
Dielectrical Strength (kV) 1
Dimensions (mm) 82.5W x 167H x 89D
Gland Entries 4 x M25
Maximum Cable Cross Section (mm²) 25
No. of Poles 1
Pack Quantity 20
Rated Current (A) 63
Rated Insulation Voltage AC (V) 500
Rated Short-Circuit Making Capacity - Icm (kA) 1.5
Rated Short-Time Withstand Current - Icw (kA) 0.76
Rated Voltage (V) 240
