IDECYW4L-MF2E10Q3G Illuminated Pushbutton 22mm Extended w/Full Shroud Momentary Green 12VAC/DC 1NO

Product Code: YW4L-MF2E10Q3G

  • Illuminated pushbutton with green LED
  • Durable metal bezel, IP65 front protection
  • Extended actuator with full shroud design
  • Rated for 5 million operations (single contact)
  • cULus, CE, UKCA, CCC certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 30W x 41.4H x 64.8D
Operating Voltage DC (V) 12
Operating Voltage AC (V) 12
No. of Normally-open Contacts 1
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Extended with Full Shroud
Bezel Material Metal
Colour Green
Contact Configuration 1NO
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Illuminated
Insulation Resistance 100 MOhm
Lamp Colour Green
Lamp Type Built-in LED
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Extended With Full Shroud Momentary- With LED Lamp
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Rated Voltage 12 VAC/DC
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW4L-MF2E10Q3G is a compact, illuminated pushbutton featuring a 12V green LED and designed for 22mm mounting. Its space-saving design includes a slim 10mm contact block and a removable operator for straightforward maintenance. The unit's metal bezel enhances durability, while the separate contact block simplifies installation and removal processes. This lightweight pushbutton is an efficient solution for various control panel applications.
